Automation Assisted JQL Querying - When and how it can improve your user's experience

[#1]

Introduction

The aim of this article is to create awareness of circumstances that influence the time a user has to wait for a complex database query to produce results. For this, we introduce the query footprint. We want a small footprint to gain quick results.
To get a measure of the footprint, we look at how many comparisons the computer has to make to produce the results. This is illustrated with examples using a model database with a limited amount of objects. In these examples, we see how the computer evaluates objects by their properties by comparing their property values to desired target values. The total number of these conditional comparisons (conditionals) in a query determines the overall footprint.
By comparing the performance footprint of different types of queries, we gain insight into key factors that influence the query footprint and why in some cases it is beneficial to use additional techniques such as Automation assisted querying to obtain the same results at a much quicker rate.

Single part queries that use a single property

When polling the content of a database using a single conditional, a certain property of all the objects in that database is compared to the target value. Example 1 shows how the performance footprint is defined in this case.

Example 1: The definition of the footprint of a simple query.

Let's assume we have a database with objects that have a property called Shape. The database is filled with 60 objects of a certain shape. For this exercise the database is filled with objects with their respective Shape property set to:

10 round objects 10 triangular objects 10 square objects 10 star objects 10 arrow objects 10 hexagonal objects

We have the following query to find all objects that are round or square:

     Shape = square

To compute the answer to this query, the computer iterates over the complete database of 60 objects to compare if the shape of that object meets the desired condition (in this case square). We define the footprint of a query to be the number of comparisons the computer has to make: In this query, that's 60, so the footprint of this query has a value of 60.

Multi part queries using a single property

When a query consists of multiple conditionals, each of these is executed against all objects of the database. The results are subsequently processed into an end result, which is presented to the user. The execution time increases linearly with an increasing number of conditionals, which is explained in example 2 by calculating the footprint that was defined earlier.

Example 2: Multipart query using a single property

We have the same object database as in example 1. But now we want to find the objects that are round or square:

     Shape = round or Shape = square

To compute the answer to this query, the computer first iterates over the database to find the round objects, followed by a second iteration over the database to find the star shaped objects. The query performance footprint is therefore 60 plus 60 equals 120.

Note that the above query can be somewhat optimized if the program allows for a value-checking array of property values, as in:

     Shape in (round, star)

This query only needs one iteration over the complete database, yet is a bit slower than example 1, because the objects that don't have a round shape need to be checked consecutively for being star shaped, giving it an performance footprint of 60+50 = 110.

Top tip:
As a value checks out to be a target value, the remainder of the value-checking array is skipped. This means that it is worthwhile to populate the value-checking array in order of most common value to least common value.

Multipart queries over multiple different properties

Things can get obstipated quickly when having to query multiple conditions over multiple properties. Despite what one might think is that the order of execution is not a key factor here, though syntax would suggest otherwise. It is in fact the approach of the problem that can make a decisive difference in how things pan out in terms of the performance footprint needed. Typical use case is the filter used by management when constructing a Plan (A.K.A. Roadmap view) in Jira that would have the Jira work items (epics, stories, tasks) of multiple Jira projects that hierarchically fall under management initiatives/features.

Example 3: Multipart query over multiple different properties

Let's assume that the objects in our database have two properties: Shape and Color. As in the previous examples given above we have the same 60 object, yet each has a random color value chosen from the values red, white and blue.

     Our goal is to find the red colored circles and red colored triangular objects.

There are a couple of different approaches to this problem: the hardest way (a), the hard way (b) and the smart way (c). Each approach will start be explained with the model database example.

Approach A: Select all and remove what isn't matching other criteria

This approach is based on gathering all possible objects and subsequently eliminating the objects that do not match an other property.

     (Shape = circle or Shape = triangles) and (Color != white or Color !=blue)

This query needs 120 iterations for the Shapes, followed by 120 iterations to assess all the unwanted objects by color, followed by 20 iterations to check the combination of found shapes against the objects having the unwanted colors, giving this query a total footprint of a whopping 260.

Approach B: Select all and then remove what is matching other criteria

This approach is based on gathering all possible objects and subsequently eliminating the objects that match an other property.

     (Shape = circle or Shape = triangle) and (Color = red)

This query needs 120 iterations for the Shape, followed by 60 iterations to assess all objects with the wanted color, followed by 20 iterations to check the combination of found shapes against the objects having the correct color, giving it a total footprint of 200. So these tactics are marginally better than approach A.

Approach C: Use of automations assistance to pre-mark objects

Create an automation that checks on a Color change. When an object is changed to red and it happens to be a circle object or a triangle object, fill a newly created property Target with the value "true" and solely query this property. Yes, this feels like cheating, but it is in fact a pre-marking of the wanted objects at a time the user isn't using the query to select the objects. The user experience during querying is greatly enhanced as the query is simplified drastically to:

     Target = true

Similar to example 1, this query yields the correct results with a total performance footprint of 60. Yes, it also needs the execution time of the automation, and we need an initial script to tag targets that are already in the database, but the execution of these automations does NOT coincide with the moment that the user wants to execute the query.

Finding the correct trigger for the automation isn't that hard: a parent link change trigger can be used to pinpoint work items that should be tagged the moment they are attached to a management initiative. Somewhat more of a challenge would be dealing with multiple management domains (read: multiple tags). Especially when project contributions span several domains, a parent link change can also lead to having to delete the proper tags.

Conclusion

There are circumstances when querying requires extra attention:

1. When the amount of objects is large (>300000 objects)
2. When the amount of properties is large
3. When the amount of conditional values for a property is large

In the extreme cases where combinations of the above occur, a tailored solution such as approach C is preferred to prevent severe degradation in Jira query performance. Coordination with your Jira Administrator is in these cases highly recommended.

[Bill Sheboy]

Hi @Dick

Thanks for your article describing trading-off storage for query performance using automation.  This technique may also help when the built-in features of JQL do not support the needed query (e.g. complicated date / time evaluation), using an "indicator" custom field for the desired condition.  One risk (particularly for Cloud sites) is covering all possible paths that change inputs to the indicator with automation...including outages preventing execution of the rules when expected.

Kind regards,
Bill

[Normann P_ Nielsen _Netic_]

Greate article and as an IT Guy, I am familiar with the text and I understand the impact.

But - to be honest also - and in perspective of a normal user - in our organisation using a lot of other tools like splunk and elasticsearch, some SQL, PowerBI etc etc - I problably do not know all - JQL as today (we are on DC) is so lacking of just basic features - like compare a text field to a text field, or using simple things / function like toLower(), SubSting(), inStr(), eval etc etc - how about starting there :-)

And field to field compare, concat string, if and evaluations.

BR,

Normann

[Dick]

Hi @Bill Sheboy and @Normann P_ Nielsen _Netic_

To illustrate the above: We have four managerial domains, that put their long term and sub-long term ideas into two top-issuetypes, each in their own project (A, B, C, D).

Next to these, we have agile groups working on epics with their tasks and stories. Each Group works for one of the domains, but can do work outside "their" domain, for the other three domains, so to speak.

Management (ie. manager of domain A) wants to have a plan (roadmap) overview that contains:

1. All long term and sub-long term issues of domain A.
2. All long term and sub-long term issues of domains B, C, and D that have a contribution of an agile group of team A.
3. All epics of the teams that regularly (hierarchically) work for domain A.
4. All epics of the B, C, D agile groups that contribute to one of the issues mentioned under 1.

the four designated searchable fields I used respectively are:

1. Project = A
2. Automation that fills/removes the component "A" on the designating B, C, or D top level issues if they contain epic children belonging to groups working in domain A
3. ProjectCategory = A
4. Automation that fills the custom field Targeted Domain on an epic depending on the parent that receives this epic child.

The nitty gritty is in capturing all possible epic-manipulations. Lucky for me, this can be caught by using the on change of an issue's parent link and checking the old-parent and new-parent top level issue accordingly. For Domain A, this results in the following query:

      Project = A or component = A or ProjectCategory = A or Targeted Domain = A

We also have an automation that can initialize the component field and Targeted Domain field values according to the existing hierarchical arrangement of top level issues types and epics. This automation can be used in case of a temporary malfunction of automations.

Kind regards,
Dick

[Normann P_ Nielsen _Netic_]

Hi @Dick

Sorry - I mistook the article as an Atlassian article, by an Atlassian Employee, so my point were not an attack on You or the text - actually I really appriciate such tecnical sulotions to facilite some end fuction gold - Thumbs up :-)

I just wish that Atlassian would improve the search engive where and with common functions that are generally available in most other applications.

BR,

Normann

[Dick]

Dear @Normann P_ Nielsen _Netic_

No need to say you're sorry here. I didn't interpret your point as an attack. It only motioned me to enlighten what and how I realized this fair trade-off between storage and query performance (thank you @Bill Sheboy , perfectly put!).

Kind regards to both of you,
Dick

[Matt Doar _Adaptavist_]

Understanding how searches work in any tool is a good idea. Real databases of course do lots of clever things such as indexes, so the details are more complex. Doing some of the indexing work up front by creating values in custom fields is one way to reduce the footprint, for sure, but there is the tradeoff if the query changes over time and you have to regenerate the field values.

JQL is intended to be a general purpose query mechanism, and it does it pretty well even in large Jira instances, in my experience. For Data Center, I see that there is a plan to make it possible to use other search mechanisms: https://community.developer.atlassian.com/t/introducing-opensearch-for-jira/83458
But Jira Cloud may already be using non-Lucene indexes, I'm not sure
