How can I delete a diagram from Apps-Draw io Diagrams list?

Question

Hei,

I inserted couple of ugly drawio diagrams to my confluence page and deleted them from my confluence attachment but they are still on drawio diagrams list.  It says diagram not found when I click on them, which is normal. What is the way of deleting them?

Thanks in advance.

Bastian Schmitt -drawio Diagrams- · Answer

Thank you @Michael Stahl for the answer. The original question somehow managed to get around all our filters (probably because of the space between draw and io) so thanks for stepping in :D

Michael Stahl · Answer

Found the answer!

First, delete the drawing as Bahadir did and as explained here:

https://community.atlassian.com/t5/Confluence-questions/Deleting-a-draw-io-diagram/qaq-p/2265723

Apps -> Manage Apps -> Expand the details of Draw.io -> select the Configure button.

Select "draw.io re-indexing" (beta)

Optional: Select the space you want to clean up

Click Start Indexing.

Note: The page that contained (the deleted) drawing must not be open in edit mode.

Michael Stahl · Answer

+1. Looking also for an answer!
